Aluminium Expanded Metal Mesh Sheet Diamond Shaped Patterns ISO9001 Approved
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $2/Square Meter >30 Square Meters $1/Square Meter |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /15 Days |
|
Detail Information |
|||
| Product Name: | Standard(Raised) Aluminuml Expanded Metal Sheet Mesh | Material: | Aluminum Sheet |
|---|---|---|---|
| Application: | Protecting Mesh,Screen,Fencing | Type: | Expanded Mesh |
| Weave Style: | EXPANDED METAL | Hole Shape: | Diamond Hole |
| Wire Diameter: | Requirement | Thickness: | 0.5-8mm |
| Usage: | Construction | Packing: | Wooden Box,On Your Request,pallet |
| Short Way Of Mesh: | 2mm-50mm | Advantage: | Rich Experience,High Quality With Good Prices,good Worker |
| High Light: | Aluminium Expanded Metal Mesh,Expanded Metal Mesh Sheet,ISO9001 Expanded Steel Sheet Mesh |
||
Product Description
Standard(Raised) Aluminuml Expanded Metal Sheet Mesh Aluminium Expanded Metal Mesh
Expanded metal mesh products consist of sheets or coils of solid metal that feature a diamond pattern that vary by gauge, type of material and size of the diamond. The term “expanded metal” refers to the way the metal is simultaneously die-cut and expanded as it moves through the progressive dies on a press. This process allows it to be expanded up to 10 times its original size, while losing up to 80 percent of its original weight per square foot and retaining its form and rigidity.
Expanded metal mesh is a type of metal stock that features diamond-shaped patterns that are produced by simultaneously slitting and stretching the material. The standard form of this material is known as raised expanded metal, due to its elevated diamond pattern. Raised standard metal consists of bonds and strands that are set at a uniform angle to the plane of the metal sheet, resulting in additional strength and rigidity.
Our expanded sheet metal mesh materials include aluminum, carbon steel, stainless steel and galvanized steel. Expanded Metal stainless steel sheet is available through our company in flattened or standard (raised) styles with a variety of options in thickness, area, pattern, design, opening and more.
The following is the specific data table of the standard(raised) aluminum expanded metal sheet mesh :
|
Style |
Lbs. Per |
Design Sizes |
Opening Size |
Approx. Strand Size |
Overall Thickness |
Approx. No. |
Open Area |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SWD | LWD | SWO | LWO | Thickness | Width | SWD | LWD | ||||
| 1/2" x .051F | 27 | .50 | 1.20 | .375 | .937 | .051 | .093 | .158 | 24 | 10 | 65 |
| 1/2" x .081 | 44 | .50 | 1.20 | .375 | .937 | .081 | .096 | .186 | 24 | 10 | 60 |
| 3/4" x .051 | 17 | .923 | 2.00 | .812 | 1.75 | .051 | .109 | .200 | 13 | 6 | 78 |
| 3/4" x .081L | 32 | .923 | 2.00 | .750 | 1.68 | .081 | .129 | .220 | 13 | 6 | 76 |
| 3/4" x .081H | 41 | .923 | 2.00 | .750 | 1.68 | .081 | .165 | .300 | 13 | 6 | 69 |
| 3/4" x .125 | 65 | .923 | 2.00 | .687 | 1.68 | .125 | .169 | .305 | 13 | 6 | 68 |
| 1-1/2" x .081 | 22 | 1.33 | 3.00 | 1.187 | 2.50 | .081 | .128 | .240 | 9 | 4 | 85 |
| 1-1/2" x .125 | 43 | 1.33 | 3.00 | 1.187 | 2.50 | .125 | .162 | .300 | 9 | 4 | 79 |
The standard(raised) aluminum expanded metal sheet mesh has the characteristics of no rust, beautiful color, gorgeous color, beautiful appearance, sturdiness and durability, high quality and high grade. When the color aluminum mesh is used in architectural decoration for outdoor curtain walls, due to its unique solidity of metal materials, it can easily resist the invasion of unfavorable weather factors such as storms, and is easy to maintain. From a purely viewing point of view, metal mesh It has the characteristics of silk fabrics and gives people a visual enjoyment. When used as an indoor roof or partition wall, the unique permeability and gloss of its material give the space more aesthetic pleasure.
