SWG42 80X80 Mesh Brass Filter Screen Mesh / Filtering Woven Brass Mesh
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
| Model Number: | 80X80Mesh |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $8/Square Meter >30 Square Meters $6/Square Meter |
| Packaging Details: | paper tube inside+ wodden box +plastic bag |
| Delivery Time: | 3-10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 Rolles Per Month |
|
Detail Information |
|||
| Product Name: | SWG40 80X80 Mesh Brass Wire Mesh | Name: | Brass Wire Mesh |
|---|---|---|---|
| Application: | Woven Wire Mesh | Material: | Brass Wire |
| Hole Shape: | Square Hole | Technique: | Woven |
| Width: | Common Width 1m | Usage: | Liquid Filter,smoking Filter,Industry |
| Mesh: | 80X80 Mesh | Weave Style: | Plain Weave,double Crimp,twill Weave |
| Wire Diameter: | Requirement | Color: | Golden Or Yellow |
| Length: | 30.0m/Roll | Mesh Size: | 1*30m 1.2*30m 1.5*30m |
| High Light: | 80X80 Mesh Brass Filter Screen Mesh,SWG42 Brass Filter Screen Mesh,Filtering Woven Brass Mesh |
||
Product Description
SWG42 80X80 Mesh Brass Mesh Fabric Woven Brass Mesh For Sieving And Filtering
Brass wire mesh is produced in plain weave or twilled weave, it is also called brass wire cloth and brass wire fabric. Brass is an non-ferrous metal alloy made of copper and zinc, the zinc can increases abrasion resistance and allows for higher tensile strength. With the features, the brass wire mesh are widely used in the filtration and separation industries.
We can offer brass wire mesh in the standard specifications, apertures range from 0.077 mm to 4 mm, while wire diameters range from 0.05 mm to 0.7 mm, and the manufactured width from 36 inch to 72 inch. The standard materials are grade 65/35 or grade 70/30 brass wire.
SWG40 80X80 mesh brass wire mesh is one of the most popular varieties of our brass woven net products. Its wire diameter is 0.12mm (0.0047``), the opening is 0.198mm (0.0078``), and the opening rate is 38.69%. The width is 36 inches, 40 inches, 48 inches, 60 inches, 72 inches and so on. Standard Roll length is 100Feet, we also can cut to requested size as customers’ requirement.
Brass wire mesh has a wide range of characteristics:
60-80% Copper + 15-40% Zinc.
Flexibility, better ductility, easy to bend and easy to form.
Excellent abrasion resistance and tensile strength.
Brass wire mesh is a quite hard material, very suitable for architectural applications.
The natural golden yellow metallic color is very suitable as decorative application.
Good thermal and electrical conductivity.
Corrodes when exposed to ammonia and other salts, but not easy to rust in most cases.
The cost of brass mesh is the lowest among all copper mesh products. When conductivity is not very important, the brass mesh is a good choice.
Some common industries and applications that use brass wire mesh:
High-end Infill Panels
Room Separation & Dividers
Ceiling Panels
Fireplace Screens
Cabinet Screens
Plumbing Screens
Soffit Screen
Art Design and Creativity
Decorative Lampshades
Decorative Signage
Oil Strainers
Gutter Guards
Air Vents
Sculpture
Filter Discs
Liquid Filtration & Particle Separation
