12x64 Mesh Stainless Steel Dutch Wire Mesh / 200 Micron Filter Cloth
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
| Model Number: | 12x64 Mesh |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $2/Square Meter >30 Square Meters $1/Square Meter |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /15 Days |
|
Detail Information |
|||
| Product Name: | 12x64 Mesh Dutch Weave Micronic Filter Cloth | Type: | Weave Wire Mesh |
|---|---|---|---|
| Material: | Stainless Steel Wire,304,316 | Usage: | Filter |
| Length: | 1-30m | Feature: | Acid-resisting,Anti-corrosion,alkali-resisting Etc |
| Width: | Usually1M | Advantage: | Factory Direct Sale |
| High Light: | 12x64 Stainless Steel Dutch Wire Mesh,200 Micron Filter Cloth |
||
Product Description
T304/T316 12x64 Mesh Dutch Weave 200 Micron Filter Cloth
Dutch Weave Wire Mesh is also known as stainless steel dutch woven wire cloth and stainless steel filter cloth. It is usually made of mild steel wire and stainless steel wire. Stainless steel dutch wire mesh is extensively utilized as filter fittings for the chemical industry, medicine, petroleum, scientific research units, due to its stable and fine filtration capability.
Mesh with a Dutch weave is woven to a precise tolerance for a much denser finished material with small, curved tunnel-shaped openings. Light does not pass through Dutch-woven micronic filter mesh. Thick and sturdy Dutch weaves are typically used for hydraulic fluid filters, gas diffusers, vacuum filters, pressure liquid filters, and breather vents.
Dutch weave is divided into plain Dutch weave and twill Dutch weave. 12x64 Mesh uses plain Dutch weave.
| U.S. | Metric | |
| MESH SIZE | 12x64 per in | 12x64 per 2.54 cm |
| WIRE DIAMETER | 0.0230x0.0160 in | 0.5842x0.4064 mm |
| OPENING | 0.0079 in | 0.20066 mm |
| OPENING MICRONS | 200 | 200 |
| POROSITY | 66 | 66 |
| OVERALL THICKNESS | 0.0550 in | 1.3970 mm |
| WEIGHT/SQUARE FOOT | 0.7600 lb | 0.3450 kg |
Features
.200 micron precision woven stainless steel screen
.Our heaviest dutch weave
.Light tight mesh
.Meets ASTM E2814-18
.UNS S30400
