316 Stainless Steel Woven Wire Cloth 16X16 Mesh 0.028 Inch 0.025 Inch
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
| Model Number: | 16X16Mesh |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $2/Square Meter >30 Square Meters $1/Square Meter |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /15 Days |
|
Detail Information |
|||
| Name: | 304 316 16Mesh Plain Woven Stainless Steel Wire Mesh | Application: | Mining,Protecting Mesh |
|---|---|---|---|
| Type: | Weave Wire Mesh | Weave Style: | Plain Weave |
| Technique: | Woven | Material: | Stainless Steel Wire |
| Wire Diameter: | Requirement | Product Name: | T-304 4F X 100F Square Hole 16X16 Mesh Stainless Steel Wire Netting |
| Feature: | Acid-resisting,Anti-corrosion,alkali Resist | Color: | Silver |
| Hole Shape: | Square Hole | Advantage: | Factory Direct Sale,competitive Price |
| Sample: | Free , Avaliable | ||
| High Light: | ISO9001 Stainless Steel Woven Wire Cloth,0.028 Inch Stainless Steel Woven Wire Cloth,SS316 Wire Mesh |
||
Product Description
T-304 4F X 100F Square Hole 16X16 Mesh Stainless Steel Wire Netting For Sieving
The wire diameters suitable for the production of 16X16mesh stainless steel wire woven mesh are 0.028In., 0.025In.,0.023In., 0.020In. ,0.018In., 0.016In., 0.012In., 0.011In.The following are detailed data about this product:
| Mesh |
Construction Type |
Wire Diameter |
Width of Opening |
% of Open Area |
Weight |
|
16X16
|
Plain Weave
|
0.028 Inch | 0.035 Inch | 30.47% | 0.902 lb/ft² |
| 0.025 Inch | 0.038 Inch | 36.00% | 0.706 lb/ft² | ||
| 0.023 Inch | 0.040 Inch | 39.94% | 0.592 lb/ft² | ||
| 0.020 Inch | 0.043 Inch | 46.24% | 0.441 lb/ft² | ||
| 0.018 Inch | 0.045 Inch | 50.69% | 0.354 lb/ft² | ||
| 0.016 Inch | 0.047 Inch | 55.35% | 0.277 lb/ft² | ||
| 0.012 Inch | 0.051 Inch | 65.29% | 0.154 lb/ft² | ||
| 0.011 Inch | 0.052 Inch | 67.90% | 0.129 lb/ft² |
| T304 Stainless Steel-Standard Chemical Composition | |||||||
| Maximum Carbon (C) | Maximum Manganese (Mn) | Maximum Phosphorus (P) | Maximum Sulphur (S) | Maximum Silicon (Si) | Chromium (Cr) | Nickel (N) |
Maximum Nitrogen (N) |
|
0.08 %
|
2.0 %
|
0.045 %
|
0.03 %
|
1.00 %
|
18.00 to 20.00 % |
8.00 to 10.50 % |
0.10 %
|
|
The most important elements in 304 are Ni and Cr, but they are not limited to these two elements. The specific requirements are stipulated by the product standards. The common judgment in the industry is that as long as the Ni content is greater than 8% and the Cr content is greater than 18%, it can be considered as 304 stainless steel. This is why the industry will call this type of stainless steel 18/8 stainless steel. 304 is a versatile stainless steel, which is widely used to make equipment and parts that require good overall performance (corrosion resistance and formability). In order to maintain the inherent corrosion resistance of stainless steel, steel must contain more than 18% chromium and more than 8% nickel. |
|||||||
Features:
1. Good acid resistance, alkali resistance and corrosion resistance;
2. High strength, strong tensile force, toughness and abrasion resistance, durable;
3. Resistant to high temperature oxidation, the nominal temperature of 304 stainless steel
4. screen is 800 degrees Celsius
5. Processing at room temperature, easy to make various shapes;
6. High smoothness, no need for surface treatment, convenient and simple maintenance.
Some of the more popular applications and industries that use T-304 16X16mesh stainless steel wire mesh are listed below:
1. Used for sieving and filtering under acid and alkali environmental conditions, as a sieving net in the petroleum industry, and as a sieving net in the chemical and chemical fiber industry.
2. Used in mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries.
3. Used for screening and filtering under acid and alkali environmental conditions, as a mud mesh in the petroleum industry, as a screen in the chemical and chemical fiber industry, and as a pickling mesh in the electroplating industry.
