Rectangle Hole 1x2 1 X 1 Welded Wire Mesh Stainless Steel Sheets Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
| Model Number: | stainless steel welded wire mesh |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | USD $0.5-$5 Square Meter |
| Packaging Details: | paper tube inside+ wodden box +plastic bag |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000 Square Meter Per Month |
|
Detail Information |
|||
| Hole Shape: | Square,Rectangle | Wire Gauge: | 0.5mm-14mm |
|---|---|---|---|
| Application: | Construction Wire Mesh,Fence Mesh,building,bridge,garden Fence | Type: | Welded Mesh |
| Aperture: | 1/2",1/4"-6",1" X 2" Ect,3/4" X 3/4" 3/8"x3/8" 1" X 1'' | Width: | 0.5m To 2.2m |
| Length: | 30m | Usage: | Protection,building,Agriculture,construction,garden |
| Packing: | Waterproof Paper,Pallet,In Roll | Product Name: | Welded Wire Mesh |
| Wire Diameter: | 1.0mm~4.50mm | ||
| High Light: | rectangle hole 1 x 1 welded wire mesh,stainless steel 1 x 1 welded wire mesh,1x2 welded stainless steel wire mesh |
||
Product Description
Stainless Steel Welded Mesh 1x1 Welded Wire Mesh Welded Wire Mesh Sheets Welded Wire Mesh Screen 1x2 Welded Wire Mesh
Stainless steel welded wire mesh panels and rolls are metal mesh products formed by welding a series of crisscrossed stainless wires together by a resistance welding machine. Welded mesh with 3-25mm (1/8-1 in.) openings is also called hardware cloth.
This welding structure makes the mesh openings not easily deformed by external forces. Because 304 and 316 stainless steel have excellent corrosion resistance, it is more resistant to rust than galvanized weld mesh, especially at the welding points where the wires cross. Therefore, stainless steel welded wire mesh has a much longer service life than galvanized material.
Stainless steel welded mesh has uniform grid patterns, the delivery conditions are usually rolls, sheets or panels, depending on the wire diameter and customer requirements. The commonly used materials are available in 201, 202, 304, 304L, 316, 316L, other grades can be customized according to customer requirements.
Specifications Of Stainless Steel Wire Mesh Rolls
Stainless steel welded wire mesh rolls used for hardware cloth, available in welded and woven structure.
Type Mesh Size Diameter Weight (Approximate)
mm in. mm in. kg/m2 lb/100 ft2
Woven 3.2 1/8 0.439 0.0173 1.86 38
Welded 6.4 1/4 0.551 0.0217 1.66 34
Woven 6.4 1/4 0.655 0.0258 1.86 38
Woven 8.5 1/3 0.805 0.0317 1.77 36
Welded 8.5 1/3 0.805 0.0317 0.65 13
Welded 10.6 3/7 0.899 0.0354 1.21 25
Welded 12.7 1/2 0.655 0.0258 1.86 38
Welded 12.7 1/2 0.805 0.0317 1.66 34
Woven 12.7 1/2 1.04 0.041 0.78 16
Welded 12.7 1/2 1.04 0.041 2.54 52
Welded 12.7 1/2 1.57 0.062 1.22 25
Welded 12.7 x 25.4 1/2 x 1 1.04 0.041 1.32 27
Welded 12.7 x 25.4 1/2 x 1 1.45 0.057 0.70 14
Welded 12.7 x 25.4 1/2 x 1 1.57 0.062 0.47 10
Welded 15.9 5/8 1.20 0.047 1.11 23
Welded 19.0 3/4 1.04 0.041 1.11 23
Welded 19.0 3/4 1.45 0.057 1.27 26
Welded 19.0 3/4 1.57 0.062 1.22 25
Welded 25.4 x 12.7 1 x 1/2 1.45 0.057 0.69 14
Welded 25.4 x 12.7 1 x 1/2 1.57 0.062 1.07 22
Specifications Of Heavy Duty Stainless Steel Welded Wire Mesh Panels
The heavy duty stainless steel welded wire mesh panels has a larger wire diameter and mesh size.
Mesh Size Wire Gauge (BWG)
Inch mm
1/4″ x 1/4″ 6.4mm x 6.4mm 22, 23, 24
3/8″ x 3/8″ 10.6mm x 10.6mm 19, 20, 21, 22
1/2″ x 1/2″ 12.7mm x 12.7mm 16, 17, 18, 19, 20, 21, 22, 23
5/8″ x 5/8″ 16mm x 16mm 18, 19, 20, 21
3/4″ x 3/4″ 19.1mm x 19.1mm 16, 17, 18, 19, 20, 21
1″ x 1/2″ 25.4mm x 12.7mm 16, 17, 18, 19, 20, 21
1-1/2″ x 1-1/2″ 38mm x 38mm 14, 15, 16, 17, 18, 19
1″ x 2″ 25.4mm x 50.8mm 14, 15, 16
2″ x 2″ 50.8mm x 50.8mm 12, 13, 14
