Galvanized Welded Wire Mesh Panel 6 Gauge Anti Corrosive Anti Rust
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $5/Square Meter >30 Square Meters $3/Square Meter |
| Delivery Time: | 3-10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /30 Days |
|
Detail Information |
|||
| Name: | Galvanized Welded Wire Mesh Panel | Hole Shape: | Square,Rectangle,long Hole |
|---|---|---|---|
| Wire Gauge: | 2mm-6mm | Application: | Construction Wire Mesh,building,bridge |
| Material: | Galvanized Iron Wire | Type: | Welded Mesh,Panel Or Roll |
| Aperture: | 1" X 2" Ect,3/4" X 3/4" 3/8"x3/8" 1" X 1'' | Surface Treatment: | Hot Dipped Galvanized,galvanized/pvc Coated |
| Width: | 0.5-2m | Length: | 5m |
| Usage: | Protection,Agriculture,construction | Packing: | Pallet |
| Hole Size: | 6.35mm-152.4mm(1/4"- 6" ) | ||
| High Light: | Galvanized Welded Wire Mesh Panel,1x1 Galvanized Welded Wire Mesh,6 Gauge Wire Mesh Panel |
||
Product Description
Galvanized Welded Wire Mesh Panel Galvanized Welded Mesh Panels Welded Mesh Panels For Fence
The galvanized welded mesh panel is made of high-quality iron wire and welded by precise automatic machinery. After the welding is completed, it is galvanized. Galvanizing treatment is generally divided into electro-galvanizing treatment and hot-dip galvanizing treatment.
|
Diameter of Wire (mm) |
Mesh (Inch) |
Length (m) |
Width (m) |
Weight (kg/㎡;) |
| 250-400 | 1*1 | 0.3-4 | 0.3-2.5 | 3.125-8 |
| 250-600 | 2*2 | 0.3-4 | 0.3-2.5 | 1.56-9 |
| 250-900 | 3*3 | 0.3-4 | 0.3-2.5 | 1-14 |
| 250-1200 | 4*4 | 0.3-4 | 0.3-2.5 | 0.8-19 |
| 300-1400 | 5*5 | 0.3-4 | 0.3-2.5 | 1-21 |
| 300-1400 | 6*6 | 0.3-4 | 0.3-2.5 | 0.7-16 |
We can also customize galvanized welded mesh panels with different apertures, different wire diameters and different sizes according to your needs.
Assortments:
* Hot dipped galvanized after welding.
* Hot dipped galvanized before welding.
* Electro galvanized after welding.
* Electro galvanized before welding.
Characteristics
Smooth mesh surface ,well-proportioned meshes,strong welded points and bright luster ;
The mesh doesn’t come loose even if cut in parts or being exerted force on parts ;
Compared with general iron wire ,the products are better in respects of anti-corrosive and anti-rust.
Application :
Because galvanized welded mesh panel has excellent characteristics such as smooth mesh surface, strong structure, strong corrosion resistance and strong protection ability, it is widely used in fence.For example: orchard fence, garden fence, workshop fence, airport fence, bridge fence, construction site fence and so on.
