2x2 Galvanized Welded Wire Mesh For Agriculture / Construction
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $5/Square Meter >30 Square Meters $3/Square Meter |
| Delivery Time: | 3-10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /30 Days |
|
Detail Information |
|||
| Name: | Galvanized Welded Wire Mesh Panel | Hole Shape: | Square,Rectangle,long Hole |
|---|---|---|---|
| Wire Gauge: | 2mm-6mm | Application: | Construction Wire Mesh,building,bridge |
| Type: | Welded Mesh,Panel Or Roll | Aperture: | 1" X 2" Ect,3/4" X 3/4" 3/8"x3/8" 1" X 1'' |
| Surface Treatment: | Hot Dipped Galvanized,galvanized/pvc Coated | Width: | 0.5-2m |
| Material: | Galvanized Iron Wire | Length: | 5m |
| Usage: | Protection,Agriculture,construction | Packing: | Pallet |
| Hole Size: | 6.35mm-152.4mm(1/4"- 6" ) | ||
| High Light: | 2x2 Galvanized Welded Wire Mesh,Welded Wire Mesh 2x2,Welded Galvanized Wire Mesh |
||
Product Description
Galvanized Welded Wire Mesh Panel 2x2 Galvanized Welded Wire Mesh Welded Wire Mesh Fence
Galvanized Welded Wire Mesh Panel is made from high quality low carbon steel wire or Galvanized wire by automtic Welded equipment. Galvanized welded wire mesh panel is a kind of galvanized welded wire mesh, but it is thicker than galvanized welded wire mesh and has a larger mesh.
Characteristics
Smooth mesh surface ,well-proportioned meshes,strong welded points and bright luster ;
The mesh doesn’t come loose even if cut in parts or being exerted force on parts ;
Compared with general iron wire ,the products are better in respects of anti-corrosive and anti-rust.
Assortments:
* Hot dipped galvanized after welding.
* Hot dipped galvanized before welding.
* Electro galvanized after welding.
* Electro galvanized before welding.
* PVC coated.
* Black wire
Application:
It is widely used as construction, fencing, decoration and machinery protecting in industry, agriculture, traffic and transportation, mining, court, lawn and cultivation,etc.
Specification of welded wire mesh panel
| Mesh(Inch) | Mesh(mm) | Wire Diameter(BWG) |
| 1”X1” | 25X25mm | 10-16 |
| 1.5”X1.5” | 40X40mm | 10-14 |
| 2”X2” | 50X50mm | 8-14 |
| 2.5”X2.5” | 60X60mm | 8-14 |
| 3”X3” | 75X75mm | 6-12 |
| 4”X4” | 100X100mm | 6-10 |
| 5”X5” | 125X125mm | 4-10 |
| 6”X6” | 150X150mm | 4-10 |
| Special size been available based on customers’ request | ||
