Stainless Steel Welded Wire Mesh 304 Square Welded Wire Mesh 2x2 Welded Wire Mesh
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $12/Square Meter >30 Square Meters $10/Square Meter |
| Delivery Time: | 3-10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 square meter /30 Days |
|
Detail Information |
|||
| Hole Shape: | Square,Rectangle,long Hole | Wire Gauge: | 0.5mm-14mm |
|---|---|---|---|
| Application: | Construction Wire Mesh,Fence Mesh,building | Type: | Welded Mesh |
| Aperture: | 1/2",1/4"-6",1" X 2" Ect,3/4" X 3/4" 3/8"x3/8" 1" X 1'',5/8" | Width: | 0.5-2m |
| Length: | 30m | Usage: | Protection,Agriculture,construction,garden |
| Packing: | Waterproof Paper | Product Name: | Welded Wire Mesh |
| Color: | Silver | Name: | Stainless Steel Welded Wire Mesh |
Product Description
Stainless Steel welded wire mesh is made of high quality stainless steel wire and welded by advanced computer-controlled machines. Stainless steel welded wire mesh is corrosion resistant, uniform in appearance and available from stock or through custom manufacturing.
Aside from stainless steel’s corrosion resistance and clean look, another benefit of selecting a stainless steel welded wire mesh is that because the wires are physically welded at each intersection, the mesh will remain intact and rigid. Strong and consistent welds make stainless steel welded wire mesh an ideal option for general industrial use because welded mesh can be cut down to smaller sizes, like rectangles, squares or discs, without fraying, which can occur when fabricating with a woven mesh.
Specification:
All the spacing between wires are controlled by an automatic mechanism of high reliability. So the welded wire mesh size like wire diameters, opening size and panel weight are all available in a wide range. According to its size it can be made into panels and rolls. The materials and size can be chosen from a wide range.
Materials: SS201, SS202, SS302, SS304, SS304L, SS316, SS316 and so on.
Wire diameter: from 0.6 mm to 3.0 mm.
Mesh opening: mini 6.4 mm and max 200 mm is available.
Stainless Steel welded wire mesh Application: Like virtually all wire mesh and wire cloth, stainless steel welded wire mesh lends itself for use in architectural, agricultural, commercial and industrial applications
Stainless Steel welded wire mesh Quality: For stainless steel welded wire mesh, the material quality control is regarded as the vital importance. Our raw material suppliers are all excellent stainless steel wire rod factories in China with more than 20 years of production experience.
| Mesh Size | Wire Gauge Diameter | ||
| In MM | In Inch | BWG No. | MM |
| 6.4mm | 1/4Inch | BWG24-22 | 0.56mm- 0.71mm |
| 9.5mm | 3/8Inch | BWG23-19 | 0.64mm - 1.07mm |
| 12.7mm | 1/2Inch | BWG22-16 | 0.71mm - 1.65mm |
| 19.1mm | 3/4Inch | BWG21-16 | 0.81mm - 1.65mm |
| 25.4x 12.7mm | 1 × 1/2Inch | BWG21-16 | 0.81mm - 1.65mm |
| 25.4mm | 1Inch | BWG21-14 | 0.81mm - 2.11mm |
| 38.1mm | 1 1/2Inch | BWG19-14 | 1.07mm - 2.11mm |
| 25.4 × 50.8mm | 1 × 2Inch | BWG17-14 | 1.47mm - 2.11mm |
| 50.8mm | 2Inch | BWG16-11 | 1.65mm - 3.0mm |
Width & Length
Panels: 3 Feet × 6 Feet, 4 Feet × 8 Feet, 5 Feet × 10 Feet, 1 M × 2 M, 1.2 M × 2.4 M, 1.5 M × 3 M, 2 M × 4 M
Rolls: Standard width is 2400 mm and length is available at your request.
Technical Note:
Standard panel length:3000 mm, width: 2400 mm.
Special size available at request.
Packing: in waterproof paper in rolls or in wooden pallets. Custom packing available at request.
Characteristic compared with PVC or Galvanized welded wire mesh:
1. The wire itself has excellent corrosion resistance, acid and alkali resistance, high temperature resistance, harsh chemicals resistance, so it can meet your demands of long exposure in corrosion environment.
2. Stainless steel welded wire mesh has flat even surface and strong structure, its high intensity makes it has long service life, even up to several decades.
3. By its very nature stainless steel wire need no additional finish, such as galvanizing or PVC to protect it, so it can compensate for its seemingly higher cost.
4. Compared with other material welded wire mesh or PVC-coated welded iron wire mesh, it is non-toxic, so it can used for food.
5. Welded wire mesh with strong integration, strong welded points, well-proportioned meshes, so it has a good strength to hold heavy weight.
6. Due to this wire mesh panels has beautiful and bright luster, it looks cleanliness and hygiene, furthermore, this kind of product is easy to clean.
