Hot Dipped Galvanized Chain Link Fence Mesh 2.0-4.8mm For Sport Field
Product Details:
| Place of Origin: | China |
| Brand Name: | FUHANG |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meter |
|---|---|
| Price: | 1-30 Square Meter $5/Square Meter >30 Square Meters $3/Square Meter |
| Delivery Time: | 8-10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2000 Rolles Per Month |
|
Detail Information |
|||
| Frame Finishing: | Hot Dipped Galvanized | Type: | Fencing |
|---|---|---|---|
| Frame Material: | Metal | Metal Type: | Galvanized Wire |
| Material: | Galvanized Wire | Application: | Sport Field , Garden |
| Product Name: | Galvanized Chain Wire Mesh Fencing | Wire Diameter: | 2.0-4.8mm |
| Sample: | Available , Free Of Charge | Certification: | ISO9001 |
| Keywords: | Chain Link Fencing Lowes Price | ||
| High Light: | Hot Dipped Galvanized Chain Link Fence,4.8mm Galvanized Chain Link Fence,Sport Field Chain Link Fence Mesh |
||
Product Description
Galvanized Chain Link Mesh Fence Chain Link Mesh Fencing Galvanized Chain Link Fence
Galvanized hot-dipped zinc coating chain link mesh fence is the most popular and inexpensive method for protecting chain-link fence systems. It is made from galvanized wire. Preferred for decades to define property lines and protect property, galvanized chain-link offers a versatile fencing solution that will provide years of maintenance-free protection. Galvanized chain link mesh fencing system all the steel components are hot-dipped zinc coated and can be used for 15years.
Application
Galvanized chain link mesh fence is widely used in construction, industrial and agricultural for a variety of purposes:
· Creation of fences and barriers on the yard or garden.
· Separation of bulk materials in construction.
· Creation of exterior and interior trim before plastering.
· Chain link mesh for slope vegetation.
· Used for poultry fencing, Galvanized chain link fence is a kind of chew proofing fence, and it suitable for big dog cage. If you use polyvinyl fence, dog may chews the polyvinyl.
Hot Dipped Galvanized chain link mesh fence panels for temporary fencing .
Specifications: chain link mesh fence opening 5 cm, gauge 11 BWG, panel size 6' × 10', round pipe of 32 mm diameter gauge 9 BWG, one more pipe welded along width of panel (6') in middle of length of pipe frame (i.e. 5') round pipe 25 mm gauge 9 BWG. vertical pipe at both end of frame should be 1.5"-2" out on both side.
Made from galvanized low carbon steel wire, galvanized chain link mesh fence has the features of resistance to moisture, corrosion resistance, excellent resistance to sudden temperature changes and high durability.
Hot dip galvanized chain link fence specifications
· Wire diameter: 2.70 mm - 4.0 mm.
· Mesh size: 30 mm × 30 mm, 40 mm × 40 mm, 50 mm × 50 mm, 100 mm × 100 mm.
· Width: 1 m, 1.5 m, 2.0 m, 2.5 m, 5 m.
· Package: 20 m/roll, 25 m/roll, 30 m/roll, 50 m/roll, 100 m/roll, or 35 kg/roll, 50 kg/roll.
| General characteristics of chain link mesh fences with zinc (Z) or zinc alloy (ZA) coated mesh | |||||||||||
| Items | Steel post with zinc, zinc alloy coating | Posts height (m) |
Pattern | Chain link fencing | Line wires (3 rows line wires) | Suitable uses | |||||
| Roll width (m) |
Size mesh (mm) |
Wire diameter (mm) |
Spacing (mm) |
Nominal diameter | |||||||
| Low carbon mild steel (mm) |
High tensile Steel (mm) |
||||||||||
| FH-90 FH-90A |
90 90A |
0.90 0.90 |
Medium Heavy | 0.90 0.90 |
50 50 |
2.50 3.00 |
430 430 |
3.00 3.55 |
3.15 3.15 |
House garden fronts and divisions | |
| FH-120 FH-120A |
120 120A |
1.20 1.20 |
Heavy Extra heavy | 1.20 1.20 | 50 50 |
3.00 3.55 |
580 580 |
3.55 4.00 |
3.15 3.15 |
Playgrounds, general purposes | |
| FH-140 FH-140A |
140 140A |
1.40 1.40 |
Medium Heavy | 1.40 1.40 | 50 50 |
2.50 3.00 |
680 680 |
3.00 3.55 |
3.15 3.15 |
General purposes, railways, house garden flanks, highways | |
| FH-140B | 140B | 1.40 | Extra heavy | 1.40 | 50 | 3.55 | 680 | 4.00 | 3.15 | Playing fields, recreation grounds | |
| FH-140C FH-140C |
140C 140D |
1.40 1.40 |
Medium Heavy |
1.40 1.40 | 40 40 |
2.50 3.00 |
680 680 |
3.00 3.55 |
3.15 3.15 |
Railways, general purposes | |
| FH-180 FH-180A |
180 180A |
1.80 1.80 |
Heavy Extra heavy |
1.80 1.80 | 50 50 |
3.00 3.55 |
880 880 |
4.00 3.00 |
3.15 3.15 |
Commercial property | |
| FH-180B | 180B | 1.80 | Heavy | 1.80 | 40 | 3.00 | 880 | 3.55 | 3.15 | Railways, general safety | |
| FH-180C FH-180D |
180C 180D |
1.80 1.80 |
Heavy Extra heavy |
1.80 1.80 | 50 50 |
3.00 3.55 |
880 880 |
3.55 4.00 |
3.15 3.15 |
Industrial security | |
| FH-180 | 180E | 1.80 | Heavy | 1.80 | 40 | 3.00 | 880 | 3.55 | 3.15 | Railways, general safety | |
| FH-215 FH-215A |
215 215A |
2.15 2.15 |
Heavy Extra heavy |
2.15 2.15 | 50 50 |
3.00 3.55 |
1055 1055 | 3.55 4.00 |
3.15 3.15 |
Commercial property | |
| FH-215B | 215B | 2.15 | Heavy | 2.15 | 40 | 3.00 | 1055 | 3.55 | Railways, general safety | ||
| FH-215C FH-215D |
215C 215D |
2.15 2.15 |
Heavy Extra heavy |
2.15 2.15 | 50 50 |
3.00 3.55 |
1055 1055 |
3.55 4.00 |
3.15 3.15 |
Industrial security | |
| FH-215E | 215E | 2.15 | Heavy | 2.15 | 40 | 3.00 | 1055 | 3.55 | 3.15 | Railways, general safety | |
|
Note: · Post Heights are of the main infill material, and exclude any ground clearance at the base, or additional height provided by extension arms for barbed wire. · Post height more than 1.80 m (include 1.80 m), the top of the fence may be barbed. And the fence shall have cranked extension arms with barbed wire, increasing the height by approx. 340 mm. |
|||||||||||
